MPX-E/R Level Sensor

Brand: Automation Products Group Inc. (APG)
The MPX Series Magnetostrictive Level sensor provides highly accurate and repeatable level readings in a wide variety of liquid level measurement applications. The MPX-R’s large, buoyant, and robust float allows it to be used in harsh applications where fouling or buildup might otherwise be of concern. The MPX-E’s lighter weight design allows it to be used in applications where space is limited.
Features
  • Class 1 Division 1 Groups C & D, Class 1 Zone 1, Class 1 Zone 2
  • Highly accurate and repeatable readings
  • 4-20 mA, RS-485 (Modbus RTU) output
  • Rugged and reliable, lengths up to 32 feet (9.75 m)
  • Dual level (interface) measurement
  • Tank volume/level, strapping table
show more

The Part Numbers & SKUs listed below have been added to Stores by Sellers, but they have not yet listed a price or inventory. Find the Part Number & SKUs you're looking for and request a quote from any of the affiliated Sellers!

1 - 48 of 60 Part Numbers
MPX-E2-AN-P2SA-60
MPX-E2-AN-P2SA-60
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (304 SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 60

Overview

  • MPX: Explosion Proof Continuous Float Level Transmitter (Magnetostrictive)
  • E: Stem Type: 1/2” Diameter, 316L SS
  • 2: Output: Single float, 4-20 mA (loop powered, 2 wire)
  • A: All Housing Die-cast Aluminum, NEMA 4X, IP68, Blue
    • Small Housing

  • N: Float 2: Not Required
  • P2: Process Connection: 2”NPT  Plug, 150#
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • A: Stem Material: 316L SS
  • 60: Stem Length: 60”
  • Safety Rating: CSA Class 1 Div 1 Groups C & D
MPX-E2-AN-P2SA-65
MPX-E2-AN-P2SA-65
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (304 SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 65

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 304 Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 65" (165.1 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.1" (2.79 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SA-72
MPX-E2-AN-P2SA-72
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (304 SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 72

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 304 Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 72"
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.1" (2.79 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SB-114
MPX-E2-AN-P2SB-114
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 114

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 114" (289.56 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.1" (2.79 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SB-118
MPX-E2-AN-P2SB-118
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 118

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 118" (299.7 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.1" (2.79 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SB-156
MPX-E2-AN-P2SB-156
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 156

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 156" (386.08 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.1" (2.79 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SB-48
MPX-E2-AN-P2SB-48
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 48

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 48" (121.9 cm)
  • Deadband:
    • Top: 10" (25.42 cm)
    • Bottom: 1.1" (2.79 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SB-54
MPX-E2-AN-P2SB-54
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 54

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.59 SG)
  • Stem Length: 54"
  • Deadband:
    • Top: 6" (152.4 mm)
    • Bottom: 1.5" (38.1 mm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4
MPX-E2-AN-P2SB-56
MPX-E2-AN-P2SB-56
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 56

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.59 SG)
  • Stem Length: 56"
  • Deadband:
    • Top: 6" (152.4 mm)
    • Bottom: 1.5" (38.1 mm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4
MPX-E2-AN-P2SB-60
MPX-E2-AN-P2SB-60
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 60

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 60"
  • Deadband:
    • Top: 10" (25.42 cm)
    • Bottom: 1.1" (2.79 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SB-66
MPX-E2-AN-P2SB-66
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 66

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 66"
  • Deadband:
    • Top: 6" (15.24 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SB-72
MPX-E2-AN-P2SB-72
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 72

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 72"
  • Deadband:
    • Top: 10" (25.42 cm)
    • Bottom: 1.1" (2.79 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SB-74
MPX-E2-AN-P2SB-74
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 74

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 74"
  • Deadband:
    • Top: 6" (15.24 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2SB-96
MPX-E2-AN-P2SB-96
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 96

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.65 SG)
  • Stem Length: 96" (243.8 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.1" (2.79 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2TB-48
MPX-E2-AN-P2TB-48
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Welded, Fixed), 48

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.59 SG)
  • Stem Length: 48" (121.9 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 150#  Plug Mount Outside, 2" NPT Welded at Coupler Top
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P2TB-96
MPX-E2-AN-P2TB-96
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2" Round 316L SST Float (0.65 SG), 2" MNPT (Welded, Fixed), 96

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2" Round 316L Stainless Steel (0.59 SG)
  • Stem Length: 96" (243.8 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 150#  Plug Mount Outside, 2" NPT Welded at Coupler Top
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-AN-P4WB-72
MPX-E2-AN-P4WB-72
APG MPX Magnetostrictive Sensor, 0.5", 4-20 mA, 2" SST Float, 4" NPT Plug Mt, Welded, 316 SST, 72"
MPX-E2-CN-P1SB-20
MPX-E2-CN-P1SB-20
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 1.38"h x 1.63"d Cylindrical 316L SST Float (0.61 SG), 1" MNPT (Slide with Adjustable Compression Fitting), 20

Overview

  • MPX: Explosion Proof and Non-Incendive Magnetostrictive Level Sensor
  • E: Stem Type: 0.5 in. diameter 316L SS
  • 2: Output: Single float, 4-20 mA (loop powered, 2 wire)
  • (Blank): Large Housing Type
    • Die-cast Aluminum, NEMA 4X, IP68, Blue

  • C: Float 1: 316L SS Cylindrical (0.65 SG)
  • N: No Float 2
  • P: NPT Plug 150#
  • 1: Mounting Size: 1" NPT
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: 316L SST Stem Material
  • 20: Total Stem Length in Inches (20")
  • End Plug Options: 0.5" Stem, Standard
  • Float Stop Options: 0.5" Stem, 316L SST, 1 piece, 0.75" OD
  • CSA Class I Division 1 Groups C & D (Max Temp. 85°C)
  • NEMA 4, Aluminum, Hazard Rating
  • Electrical Requirements: 12 to 24 Volts DC
MPX-E2-CN-P2SB-124
MPX-E2-CN-P2SB-124
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 1.38"h x 1.63"d Cylindrical 316L SST Float (0.61 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 124

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: 1.38hx1.63d in Cylindrical 316L SS (0.61 SG)
  • Stem Length: 124" (314.96 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 150# Plug Mount Outside, 2" NPT Welded at Coupler Top
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-CN-P2SB-63-90DEG
MPX-E2-CN-P2SB-63-90DEG
APG MPX Magnetostrictive Sensor, 0.5", 4-20mA, 2" NPT Plug, Slide, 316 SST, 63" Stem, 90° Bend
MPX-E2-CN-P2SB-65-90DEG
MPX-E2-CN-P2SB-65-90DEG
APG MPX Magnetostrictive Sensor, 0.5", 4-20mA, 2" NPT Plug, Slide, 316 SST, 65" Stem, 90° Bend
MPX-E2-CN-P2SB-72
MPX-E2-CN-P2SB-72
APG MPX Magnetostrictive Sensor, 0.5", 4-20 mA, 1.38hx1.63d in, 2" NPT Plug, Welded, 316 SST, 72"
MPX-E2-CN-P2SB-96
MPX-E2-CN-P2SB-96
APG MPX Magnetostrictive Sensor, 0.5", 4-20 mA, 1.38hx1.63d in, 2" NPT Plug, Welded, 316 SST, 96"
MPX-E2-CN-P2WB-30
MPX-E2-CN-P2WB-30
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 1.38"h x 1.63"d Cylindrical 316L SST Float (0.61 SG), 2" MNPT (Welded, Fixed), 30

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: 1.38hx1.63d in Cylindrical 316L SS (0.61 SG)
  • Stem Length: 30"
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: Welded
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-CN-P4SB-45
MPX-E2-CN-P4SB-45
APG MPX Magnetostrictive Sensor, 0.5", 4-20 mA, 1.38hx1.63d in, 4" NPT Plug, Slide, 316 SST, 45"
MPX-E2-CN-P4WB-42
MPX-E2-CN-P4WB-42
APG MPX Magnetostrictive Sensor, 0.5", 4-20 mA, 1.38hx1.63d in, 4" NPT Plug, Welded, 316 SST, 42"
MPX-E2-FN-P2SB-100.00-S-N1A1
MPX-E2-FN-P2SB-100.00-S-N1A1
APG MPX Magnetostrictive Sensor, 4-20 mA, 2" NPT Mt, Slide, 316L SST, 100" Stem
MPX-E2-FN-P2SB-105
MPX-E2-FN-P2SB-105
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2.19"h x 1.46"d Oval 316L SST 3A Float (0.5 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 105
MPX-E2-FN-P2SB-114
MPX-E2-FN-P2SB-114
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2.19"h x 1.46"d Oval 316L SST 3A Float (0.5 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 114

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2.19"h x 1.46"d Oval 316L Stainless Steel 3A Sanitary (0.5 SG)
  • Stem Length: 114" (289.56 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
  • **Crate required for Transport**
MPX-E2-FN-P2SB-121.5
MPX-E2-FN-P2SB-121.5
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2.19"h x 1.46"d Oval 316L SST 3A Float (0.5 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 121.5

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2.19"h x 1.46"d Oval 316L Stainless Steel 3A Sanitary (0.5 SG)
  • Stem Length: 121.5" (308.61 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E2-FN-P2SB-96
MPX-E2-FN-P2SB-96
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 2.19"h x 1.46"d Oval 316L SST 3A Float (0.5 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 96

Overview

  • Output: 4-20mA, Loop Powered, 2-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: (1) 2.19"h x 1.46"d Oval 316L Stainless Steel 3A Sanitary (0.5 SG)
  • Stem Length: 96" (243.84 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
  • **Crate required for Transport**
MPX-E3-AB-P2SA-88
MPX-E3-AB-P2SA-88
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (304 SST), Dual Float 4-20 mA Output (Loop-Powered, 3-Wire), 2" Round 316L SST Float (0.65 SG), 2" Round 316L SST Float (0.92 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 88

Overview

  • Output: Dual 4-20mA, Loop Powered, 3-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 304 Stainless Steel
  • Floats:
    • (1) 2" Round 316L Stainless Steel (0.65 SG)
    • (1) 2" Round 316L Stainless Steel (0.92 SG)

  • Stem Length: 88" (223.5 cm)
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 2" NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E4-CN-P2SB-124
MPX-E4-CN-P2SB-124
APG MPX Magnetostrictive Sensor, 0.5", Modbus, 1.38hx1.63d in, 2" NPT Plug, Slide, 316 SST, 124"
MPX-E4-CN-P2SB-52
MPX-E4-CN-P2SB-52
APG MPX Series Magnetostrictive Level Sensor, 1/2" Diameter Stem (316L SST), Modbus RTU Output, 1.38"h x 1.63"d Cylindrical 316L SST Float (0.61 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 124

Overview

  • Output: Modbus RTU, Surge/lightning protection
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 1/2" Diameter, 316L Stainless Steel
  • Float: 1.38hx1.63d in Cylindrical 316L SS (0.61 SG)
  • Stem Length: 52"
  • Deadband:
    • Top: 6" (15.2 cm)
    • Bottom: 1.5" (3.81 cm)

  • Mounting: 2" NPT Slide with adjustable Compression Fitting,
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-E4-CN-P2SB-65-90DEG
MPX-E4-CN-P2SB-65-90DEG
APG MPX Magnetostrictive Sensor, 0.5", Modbus, 2" NPT Plug, Slide, 316 SST, 65" Stem, 90° Bend
MPX-F2-TN-P2SB-120
MPX-F2-TN-P2SB-120
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Flexible Tubing with Braid (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 3" Round 316L SST Float (0.6 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 120

Overview

  • MPX: Magnetostrictive Level Sensors
  • F: Stem Type: 7/8" Diameter, Flexible Tubing with Braid, 316LSS
  • 2: Output: Single float, 4-20 mA (loop powered, 2 wire)
  • T: Top Float: 3" Round 316L Stainless Steel (0.60 SG)
  • N: Float 2:  None
  • P: Mounting Plug: NPT Plug150#
  • 2: Mounting Size: 2
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: Stem Material: 316LSS
  • 120: Stem Length: 120" (304.8 cm)

Process Connection: 3" NPT

Operating Temperature: -40°F to +185°F (-40°C to +85°C)

Deadband: Top: 10" (25.4 cm) , Bottom: 8" (20.3 cm)



CSA Class 1, Div 1, Groups C & D, Hazardous Locations

NEMA 4, IP65
MPX-F2-TN-P3SB-180
MPX-F2-TN-P3SB-180
APG MPX Magnetostrictive Sensor, 7/8"Dia Flex Tubing SST Float, 3" NPT Plug Mt, Slide, 316 SST, 180"
MPX-F2-TN-P3SB-302
MPX-F2-TN-P3SB-302
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Flexible Tubing with Braid (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 3" Round 316L SST Float (0.6 SG), 3" MNPT (Slide with Adjustable Compression Fitting), 302

Overview

  • MPX: Explosion Proof and Non-Incendive Magnetostrictive Level Sensors
  • F: Stem Type: 7/8 in. diameter Flexible Tubing with Braid, 316L SS
  • 2: Single float, 4-20 mA (loop powered, 2 wire)
  • TN: Float: 3 in. Round 316L SS (0.60 SG)
  • P: NPT Plug 150#
  • 3: 3" NPT Mounting Size
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: 316L SST Stem Material
  • 302: Total Stem Length in Inches



Media Temperature: -40°F to +185°F (-40°C to +85°C)

Electrical Connection: Terminal Block, 12-24 VDC

Materials of Construction:

Housing: Cast aluminium, epoxy coated

Stem: 7/8” ø Flexible Tubing with Braid, 316L SS

Float: 316L Stainless Steel, 3in Rnd .60SG

Rated: 12 to 24 Volts DC, 4-20mA, Ta 85°C

Class I Division 2 Groups C & D

Ex nA IIB

Class I, Zone 2; AEx nA IIB
MPX-F2-TN-P3SB-382
MPX-F2-TN-P3SB-382
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Flexible Tubing with Braid (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 3" Round 316L SST Float (0.6 SG), 3" MNPT (Slide with Adjustable Compression Fitting), 382

Overview

  • Stem Type: 7/8" Diameter, Flexible Tubing wiht Braid, 316L SS
  • Output: Single Float, 4-20mA (loop-powered, 2 wire)
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Float: 3" Round 316L Stainless Steel (0.60 SG)
  • Stem Length: 382" (970.3 cm)
  • Process Connection:  3" NPT
  • Deadband:
    • Top: 10" (25.4 cm)
    • Bottom: 8" (20.3 cm)

  • Mounting: 150# NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-F2-XN-P2SB-100
MPX-F2-XN-P2SB-100
APG MPX Magnetostrictive Sensor, 7/8"Dia Flex Tubing SST Float, 5" NPT Plug Mt, Slide, 316 SST, 100"
MPX-F2-XN-P2SB-288
MPX-F2-XN-P2SB-288
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Flexible Tubing with Braid (316L SST), Single Float 4-20 mA Output (Loop-Powered, 2-Wire), 5" Round 316L SST Float (0.52 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 288

Overview

  • MPX: Explosion Proof and Non-Incendive Magnetostrictive Level Sensors
  • F: Stem Type: 7/8 in. diameter Flexible Tubing with Braid, 316L SS
  • 2: Single float, 4-20 mA (loop powered, 2 wire)
  • XN: Float: 5 in. Round 316L SS (0.52 SG)
  • P: NPT Plug 150#
  • 2: 2" NPT Mounting Size
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: 316L SST Stem Material
  • 288: Total Stem Length in Inches

Media Temperature: -40°F to +185°F (-40°C to +85°C)

Electrical Connection: Terminal Block, 12-24 VDC

Materials of Construction:

Housing: Cast aluminium, epoxy coated

Stem: 7/8” ø Flexible Tubing with Braid, 316L SS

Float: 316L Stainless Steel, 3in Rnd .60SG

Rated: 12 to 24 Volts DC, 4-20mA, Ta 85°C

Class I Division 2 Groups C & D

Ex nA IIB

Class I, Zone 2; AEx nA IIB



MPX-F3-ZY-P2SB-384
MPX-F3-ZY-P2SB-384
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Flexible Tubing with Braid (316L SST), Dual Float 4-20 mA Output (Loop-Powered, 3-Wire), 5.5"h x 2"d Red Polyurethane Float (0.65 SG), 5.5"h x 2"d Blue Polyurethane Float (0.94 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 384

Overview

  • Output: Dual 4-20mA, Loop Powered, 3-Wire
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Stem Type: 7/8 in. diameter Flexible Tubing with Braid, 316L SS
  • Floats:
    • (1) 5.5h x 3d in. Red Polyurethane (0.65 SG)
    • (1) 5.5h x 3d in. Blue Polyurethane (0.96 SG)

  • Stem Length: 384" (975.36 cm)
  • Deadband:
    • Top: 10" (25.4 cm)
    • Bottom: 6.5" (16.51 cm)

  • Mounting: 2" NPT Plug 150#, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 2, Groups C & D,
  • Ex nA IIB,
  • Class I, Zone 2; AEx nA IIB
MPX-F4-TN-P2SB-120
MPX-F4-TN-P2SB-120
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Stem (316L SST), Modbus RTU Output, 3" Round 316L SST Float (0.6 SG), 2" MNPT (Slide with Adjustable Compression Fitting), 120

Overview

  • MPX: Magnetostrictive Level Sensors
  • F: Stem Type: 7/8" Diameter, Flexible Tubing with Braid, 316LSS
  • 4: Output: Modbus RTU, surge/lightning protection, stem RTD temperature sensor. *Note: Stem RTD's are located 6" from bottom of probe.
  • T: Top Float: 3" Round 316L Stainless Steel (0.60 SG)
  • N: Float 2:  None
  • P: Mounting Plug: NPT Plug150#
  • 2: Mounting Size: 2
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: Stem Material: 316LSS
  • 120: Stem Length: 120" (304.8 cm)

Process Connection: 3" NPT

Operating Temperature: -40°F to +185°F (-40°C to +85°C)

Deadband: Top: 10" (25.4 cm) , Bottom: 8" (20.3 cm)



CSA Class 1, Div 1, Groups C & D, Hazardous Locations

NEMA 4, IP65
MPX-F4-TN-P3SB-249
MPX-F4-TN-P3SB-249
APG MPX Magnetostrictive Sensor, Modbus RTU, SST Float, 3" NPT Plug Mt, Slide, 316 SST, 249"
MPX-F4-TN-P3SB-268
MPX-F4-TN-P3SB-268
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Stem (316L SST), Modbus RTU Output, 3" Round 316L SST Float (0.6 SG), 3" MNPT (Slide with Adjustable Compression Fitting), 268

Overview

  • MPX: Magnetostrictive Level Sensors
  • F: Stem Type: 7/8" Diameter, Flexible Tubing with Braid, 316LSS
  • 4: Output: Modbus RTU, surge/lightning protection, stem RTD temperature sensor. *Note: Stem RTD's are located 6" from bottom of probe.
  • T: Top Float: 3" Round 316L Stainless Steel (0.60 SG)
  • N: Float 2:  None
  • P: Mounting Plug: NPT Plug150#
  • 3: Mounting Size: 3
  • S: Mounting Connection: Slide with Compression Fitting (adjustable)
  • B: Stem Material: 316LSS
  • 268: Stem Length: 268" (680.7 cm)

Process Connection: 3" NPT

Operating Temperature: -40°F to +185°F (-40°C to +85°C)

Deadband: Top: 10" (25.4 cm) , Bottom: 8" (20.3 cm)



CSA Class 1, Div 1, Groups C & D, Hazardous Locations

NEMA 4, IP65
MPX-F4-TN-P3SB-305
MPX-F4-TN-P3SB-305
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Stem (316L SST), Modbus RTU Output, 3" Round 316L SST Float (0.6 SG), 3" MNPT (Slide with Adjustable Compression Fitting), 305

Overview

  • Stem Type: 1" Diameter, Flexible Tubing with Braid, 316LSS
  • Output: Modbus RTU, surge/lightning protection, stem RTD temperature sensor.
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Float: 3" Round 316L Stainless Steel (0.60 SG)
  • Stem Length: 305" (774.7 cm)
  • Process Connection: 3" NPT
  • Deadband:
    • Top: 12.25" (311.15 mm)
    • Bottom: 4.25" (107.95 mm)

  • Mounting: 150# NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-F4-TN-P3SB-331
MPX-F4-TN-P3SB-331
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Stem (316L SST), Modbus RTU Output, 3" Round 316L SST Float (0.6 SG), 3" MNPT (Slide with Adjustable Compression Fitting), 331

Overview

  • Stem Type: 1" Diameter, Flexible Tubing with Braid, 316LSS
  • Output: Modbus RTU, surge/lightning protection, stem RTD temperature sensor.
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Float: 3" Round 316L Stainless Steel (0.60 SG)
  • Stem Length: 331" (840.7 cm)
  • Process Connection: 3" NPT
  • Deadband:
    • Top: 12.25" (311.15 mm)
    • Bottom: 4.25" (107.95 mm)

  • Mounting: 150# NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
MPX-F4-TN-P3SB-382
MPX-F4-TN-P3SB-382
APG MPX Series Magnetostrictive Level Sensor, 7/8" Diameter Stem (316L SST), Modbus RTU Output, 3" Round 316L SST Float (0.6 SG), 3" MNPT (Slide with Adjustable Compression Fitting), 382

Overview

  • Stem Type: 7/8" Diameter, Flexible Tubing with Braid, 316LSS
  • Output: Modbus RTU, surge/lightning protection, stem RTD temperature sensor.
  • Operating Temperature: -40°F to +185°F (-40°C to +85°C)
  • Float: 3" Round 316L Stainless Steel (0.60 SG)
  • Stem Length: 382" (970.3 cm)
  • Process Connection: 3" NPT
  • Deadband:
    • Top: 10" (25.4 cm)
    • Bottom: 8" (20.3 cm)

  • Mounting: 150# NPT Plug Mount, Adjustable Slide with Compression Fitting
  • CSA Class 1, Div 1, Groups C & D, Hazardous Locations
  • NEMA 4, IP65
1 - 48 of 60 Part Numbers

MPX-E/R

Probe Diameter

Output

  • view details
  • view details

Housing

First Float (Top Float)

First Float (Top Float)

Float Two

Float Two

Mounting

Flat Face

Raised Face

Ferrule Size

NPT Plug Size

Mounting Type

Stem Material

Sensor Length

Float Stop

Float Stop

Optional Temperature Sensor

Output Set Points

Specifications

Accuracy

  • ± 0.05% of Span

Approvals & Certifications

  • CSA Class I, Division 1, Groups C, D T4 (Ta 84° C) Class I, Zone 1, AEx D IIB T4 Class I, Zone 2, AE

Communication

  • Interface with RS-485 Modbus RTU
  • Interface with RST-4100 Programming Module

Electrical Connectors

  • Terminal Block

Enclosure, Body Material

  • Aluminum, Epoxy Coated

Environmental Protection

  • IP65
  • IP66
  • NEMA 4X

Flange Size - 1" (DN25)

  • 1" (DN25) - 150#

Flange Size - 1-1/2" (DN40)

  • 1-1/2" (DN40) - 150#

Flange Size - 2" (DN50)

  • 2" (DN50) - 150#

Flange Size - 2-1/2" (DN65)

  • 2-1/2" (DN65) - 150#

Flange Size - 3" (DN80)

  • 3" (DN80) - 150#

Flange Size - 3-1/2" (DN90)

  • 3-1/2" (DN90) - 150#

Flange Size - 4" (DN100)

  • 4" (DN100) - 150#

Flange Size - 5" (DN125)

  • 5" (DN125) - 150#

Flange Size - 6" (DN150)

  • 6" (DN150) - 150#

NPT Connection

  • 1" NPT Male
  • 1-1/2" NPT Male
  • 2" NPT Male
  • 2-1/2" NPT Male
  • 3" NPT Male
  • 3-1/2" NPT Male
  • 4" NPT Male
  • 5" NPT Male
  • 6" NPT Male

Operating Temperature

  • -40° to 85° C (-40° to 185° F)

Output

  • 4-20 mA

Resolution

  • 0.04" (1 mm)

Sensor, Probe Style

  • Float

Supply Voltage

  • 12-24 Vdc

Tri-Clamp Connection

  • 1" Sanitary Clamp
  • 1-1/2" Sanitary Clamp
  • 2" Sanitary Clamp
  • 2-1/2" Sanitary Clamp
  • 3" Sanitary Clamp
  • 3-1/2" Sanitary Clamp
  • 4" Sanitary Clamp
  • 5" Sanitary Clamp
  • 6" Sanitary Clamp
The MPX Series Magnetostrictive Level sensor provides highly accurate and repeatable level readings in a wide variety of liquid level measurement applications. The MPX-R’s large, buoyant, and robust float allows it to be used in harsh applications where fouling or buildup might otherwise be of concern. The MPX-E’s lighter weight design allows it to be used in applications where space is limited.
Features
  • Class 1 Division 1 Groups C & D, Class 1 Zone 1, Class 1 Zone 2
  • Highly accurate and repeatable readings
  • 4-20 mA, RS-485 (Modbus RTU) output
  • Rugged and reliable, lengths up to 32 feet (9.75 m)
  • Dual level (interface) measurement
  • Tank volume/level, strapping table

Documentation
